Fiocchi Extrema Ammunition 223 Ammo is loaded with premium bullets from popular component manufacturers, a broad spectrum of cartridges are offered for competition shooters, hunters and law enforcement. Produced with precision cases and reliable Fiocchi primers, this ammunition is new production, non-corrosive, in boxer-primed, reloadable brass cases.
Hornady’s V-Max Bullets feature a polymer tip which enhances accuracy and promotes devastating expansion. The tip raises the ballistic coefficient for faster velocity and helps to stabilize the bullet in flight. It also acts as a wedge, initiating bullet expansion.
The copper jacket provides the necessary bearing surface for maximum stability out of the barrel, and the jacket is built to withstand the fast twist rates of the most advanced varmint rifles.
Note: Quantity of 200 comes in polymer ammo can with 4 boxes of 50 inside
Where are Fiocchi products made? While most of fiocchi 233 ammo is loaded at their plant in Ozark, Missouri, Fiocchi is also importing ammunition and reloading components from their plant in Italy because of the high demand the industry has been experiencing. All products are loaded to either C.I.P. or SAAMI specifications.
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to –PRODUCT INFORMATION
| Cartridge | 223 Remington |
| Grain Weight | 50 Grains |
| Quantity | 1000 Round |
| Configuration | (20 Boxes of 50) |
| Muzzle Velocity | 3300 Feet Per Second |
| Muzzle Energy | 1208 Foot Pounds |
| Bullet Style | Polymer Tip |
| Lead Free | No |
| Case Type | Brass |
| Primer | Boxer |
| Corrosive | No |
| Reloadable | Yes |
| G1 Ballistic Coefficient | 0.242 |
| Sectional Density | 0.142 |
| Velocity Rating | Supersonic |
DELIVERY INFORMATION 223 AMMO WIKI
| Shipping Weight | 27.670 Pounds |
| DOT-Regulated | Yes |
The .223 Remington has a 28.8-grain H2O (1.87 ml) cartridge case capacity.
.223 Remington maximum CIP cartridge dimensions. All sizes in millimeters (mm)
Americans would define the shoulder angle at alpha/2 = 23 degrees. The common rifling twist rate for this cartridge is 305 mm (1 in 12 in), 6 grooves, Ø lands = 5.56 millimetres (0.219 in), Ø grooves = 5.69 millimetres (0.224 in), land width = 1.88 millimetres (0.074 in) and the primer type is small rifle.
According to the official CIP rulings, the .223 Remington can handle up to 430.00 MPa (62,366 psi) Pmax piezo pressure. In CIP-regulated countries, every rifle cartridge combination has to be proofed at 125% of this maximum CIP pressure to certify for sale to consumers. This means that .223 Remington chambered arms in CIP-regulated countries are currently (2016) proof tested at 537.50 MPa (77,958 psi) PE piezo pressure. This is equal to the NATO maximum service pressure guideline for the 5.56×45mm NATO cartridge.
The SAAMI pressure limit for the bulk 223 ammo is set at 379.212 MPa (55,000 psi), piezo pressure. Remington submitted .223 Remington specifications to SAAMI in 1964.
In 1980, the .223 Remington was transformed into a new cartridge and designated 5.56×45mm NATO (SS109 or M855).
DIMENSIONS 223 AMMO PRICE HISTORY
The external dimensional specifications of .223 Remington and 5.56×45mm NATO brass cases are nearly identical. The cases tend to have similar case capacity when measured (case capacities have been observed to vary by as much as 2.6 grains (0.17 ml)), although the shoulder profile and neck length are not the same and 5.56×45mm NATO cartridge cases tend be slightly thicker to accommodate higher chamber pressures.
When hand-loaded, care is taken to look for pressure signs as 5.56×45mm NATO cases may produce higher pressures with the same type of powder and bullet as compared to .223 ammo cases. Sierra provides separate loading sections for .223 Remington and 5.56×45mm NATO and also recommends different loads for bolt-action rifles as compared to semiautomatic rifles. Rifling
The Sturm, Ruger & Co. AR-556 has rifling at 1:8. Their Mini-14 rifles have rates of 1:9. Ruger’s American bolt-action rifle is also in 1:8. Smith and Wesson in their M&P15 also uses 1:9.
PRESSURES FEDERAL 223 AMMO – 500 ROUNDS
Remington submitted the specifications for the .223 Remington cartridge in 1964 to SAAMI. The original pressure for the .223 Remington was 52,000 psi with DuPont IMR Powder. The current pressure of 55,000 psi (379 MPa) resulted from the change from IMR to Olin Ball powder. The official name for .223 Remington in the US Army is cartridge 5.56 x 45mm ball, M193. If a 5.56×45mm NATO cartridge is loaded into a chamber intended to use .223 Remington, the bullet will be in contact with the rifling and the forcing cone is very tight.
This generates a much higher pressure than 223 bulk ammo chambers are designed for. NATO chose a 178-mm (1-in-7) rifling twist rate for the 5.56×45mm NATO chambering. The SS109/M855 5.56×45mm NATO ball cartridge requires a 228 mm (1-in-9) twist rate, while adequately stabilizing the longer NATO L110/M856 5.56×45mm NATO tracer projectile requires an even faster 178 mm (1-in-7) twist rate.
